HUITE HZS180 Stationary Concrete Batching Plant -Customized Case in Kazakhstan
The HZS180 stationary concrete batching plant is one of HUITE’s core products, integrating advanced technology and stable performance, and can be customized according to local working conditions, policies and customer needs to meet the diverse requirements of large-scale infrastructure projects.
Customer Background: A large-scale construction enterprise in Kazakhstan, deeply engaged in the local infrastructure construction field, mainly undertakes the construction of highways, bridges and industrial plants.
Core Customer Needs: Combined with the actual local conditions in Kazakhstan, the customer put forward clear customized requirements, focusing on solving the pain points of local policy compliance, harsh climate, complex raw materials and insufficient labor force,.
Core Selling Points of HUITE HZS180 stationary concrete batching plant (Kazakhstan Customized Version)
Selling Point Category | Specific Selling Point | Key Data Support |
Professional Customization | Localized adaptation for Kazakhstan (climate, policy, raw materials) | -35℃ low-temperature adaptation, 8-degree seismic resistance, GOST-K certified |
High Efficiency & Stability | High production capacity and stable operation | 175 m³/h actual capacity, 98.7% low-temperature stability rate |
Superior Quality | Precise batching and high concrete qualification rate | ±1.5% batching accuracy, 99.8% concrete strength qualification rate |
Energy-Saving & Environmental Protection | Low energy consumption and up-to-standard emission | 1.1 kWh/m³ unit energy consumption, 38 mg/m³ dust emission |
Easy Operation & Maintenance | Intelligent control and remote after-sales support | 65% reduction in professional technician dependence, ≤1 hour fault handling |
Professional Export Strength | One-stop export service (customization, certification, installation) | Export to 50+ countries, 45-day GOST-K certification completion |
Customized Solutions by HUITE: In response to the customer's needs, combined with Kazakhstan's local policies, climate, raw material characteristics and labor conditions, HUITE carried out a full-dimensional customized design on the HZS180 stationary concrete batching plant, integrating advanced technology and local adaptability to create an exclusive solution suitable for local working conditions. As a professional manufacturer and export enterprise, HUITE also provides one-stop services including equipment customization.
1. Low-Temperature Adaptation Customization to Cope with Alpine Climate
Aiming at the problem that the equipment is prone to freezing and failure in the local winter low-temperature environment (-35℃), HUITE carried out targeted low-temperature adaptation upgrades, ensuring the low-temperature operation stability rate of not less than 98%. First, the electrical system of the mixing plant was optimized: all electrical components were replaced with low-temperature resistant models (operating temperature range -40℃ ~ +60℃), and the circuit was equipped with anti-condensation and anti-freezing protection devices, reducing the low-temperature failure rate of electrical components to less than 0.5%. Secondly, the hydraulic system was upgraded: low-temperature resistant hydraulic oil (with pour point ≤ -35℃ and kinematic viscosity ≥ 40mm²/s at 40℃) was used to ensure the smooth operation of the hydraulic system in low temperature.
2. Raw Material Adaptation Customization to Ensure Mixing Quality
In view of the local characteristics of uneven aggregate gradation (deviation up to 15%), large differences in cement performance (strength grade 32.5R) and large fluctuation of aggregate water content (3%-8%), HUITE optimized the structure and control system of the HZS180 stationary concrete batching plant to improve the adaptability to raw materials, ensuring the concrete strength qualification rate of not less than 99.5%. First, the aggregate batching system was upgraded: the aggregate screening device (screen mesh size 5mm, 10mm, 20mm, 40mm) was added to classify the uneven aggregate into 4 specifications, and the batching accuracy was adjusted to ±1.5% (higher than the standard ±2% of HZS180 mixing plant) to ensure the stability of aggregate ratio. Second, the mixing host was improved: the JS3000 forced double-horizontal shaft mixing host (matching the HZS180 model) was adopted, the mixing blade and liner were replaced with wear-resistant alloy materials, and the mixing structure was optimized to enhance the mixing intensity and uniformity, which can effectively solve the problem of uneven mixing caused by the difference in cement performance.
3. Operation and Maintenance Customization to Adapt to Local Labor Conditions
To solve the problems of local labor shortage (3 operators per shift) and limited operator skills, HUITE focused on optimizing the operation and maintenance convenience of the equipmen. First, the control system was upgraded to a humanized intelligent control platform with a simple and intuitive operation interface, which supports both Chinese and Russian (local common language) operation. Second, the maintenance structure was optimized: key components (such as mixing blades, liners, etc.) were designed to be easy to disassemble and assemble, reducing the disassembly and assembly time by 40%.
Technical Parameter Table of HUITE Customized HZS180 stationary concrete batching plant (Kazakhstan Version)
Parameter Category | Parameter Name | Customized Specification (Kazakhstan Version) | Standard Specification of HUITE HZS180 | Customization Purpose |
Production Capacity | Theoretical Production Capacity | 180 m³/h | 180 m³/h | Meet the project's large concrete demand |
Production Cycle | 58 seconds/batch | 60 seconds/batch | Improve production efficiency | |
Low-Temperature Adaptation | Operating Temperature Range | -40℃ ~ +60℃ | -10℃ ~ +50℃ | Adapt to local alpine climate (-35℃ minimum) |
Low-Temperature Operation Stability Rate | ≥ 98% | ≥ 85% | Ensure continuous operation in winter | |
Concrete Slump Fluctuation | ±15mm | ±20mm | Ensure stable concrete quality | |
Concrete Strength Qualification Rate | ≥ 99.5% | ≥ 98% | Meet project durability requirements (50 years) | |
Noise at 10 Meters | 72 dB(A) | ≤ 85 dB(A) | Comply with local GOST 12.1.003-83 standard | |
Operation & Maintenance | Dependence Reduction on Professional Technicians | 65% | 40% | Adapt to local labor shortage |
Fault Handling Time | ≤ 1 hour | ≤ 4 hours | Improve equipment operation efficiency |
"The HUITE HZS180 concrete mixing plant fully meets our project needs and local standards. Its customized design perfectly adapts to our alpine climate and raw material characteristics, ensuring stable operation even in -35℃ winter with a high concrete qualification rate. HUITE’s professional one-stop export service, from certification handling to on-site training, and efficient remote maintenance support, greatly reduces our operation and labor costs. We highly recognize HUITE’s product quality and service capability and look forward to long-term cooperation." —— Engineering Director of the Kazakhstan Customer
Project Operation Effect
After the HUITE customized HZS180 stationary concrete batching plant was put into use in March 2025, it has achieved stable and efficient operation. As of October 2025, the equipment has operated continuously for 210 days. The equipment has successfully withstood the test of local alpine climate, operating continuously and stably even in the winter with the minimum temperature of -35℃, with a low-temperature operation stability rate of 98.7%, without freezing or failure.
This customized case fully demonstrates the strong adaptability, professional customization capability and excellent product performance of HUITE HZS180 stationary concrete batching plant. As a professional stationary concrete batching plant manufacturer and export enterprise, HUITE deeply integrates local policies, climate, raw materials and labor characteristics of Kazakhstan, provides precise data support and targeted customized upgrades, and creates a solution fully suitable for the actual needs of the customer.
If you are seeking a high-efficiency, reliable and customized heavy-duty concrete batching solution, contact us now to obtain a detailed quotation, technical manual and customized project solution!
